K1 Series LED TVDifference contrast
- Display parameters
Backlight category
ELED
ELED
DLED
-
Aspect ratio
16:9
16:9
16:9
-
Resolution
1920*1080
3840*2160
1366*768
-
Visible area
941.184mm*529.416mm
941.184mm*529.416mm
856.482mm*472.128mm
-
Viewing angle
H:178°/V:178°
H:178°/V:178°
H:178°/V:178°
-
Dot pitch
0.2451mm*0.2451mm
0.2451mm*0.2451mm
0.62475mm*0.62475mm
-
Color
1.07B
1.07B
16.7M
-
Brightness
380cd/m²
380cd/m²
330cd/m²
-
Contrast ratio
4000:1
4000:1
5000:1
-
Response time
8ms
8ms
6.5ms
-
Image processing
3D+3D
3D+3D
3D+3D
- Power waste
Power
≤98W
≤98W
≤55W
-
Operating voltage
100V-240VAC 60/50Hz
100V-240VAC 60/50Hz
100V-240VAC 60/50Hz
-
Audio Power output
8W+8W
8W+8W
6W+6W
- Specifications
N.W.
11kg
11kg
5.5kg
-
G.W.
13.5kg
13.5kg
7.5kg
-
Remote Area
≥8m ±30°
≥8m ±30°
≥8m ±30°
- Interface type
Input interface
HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme)
HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme)
HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme)
-
Output interface
Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme)
Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme)
Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme)
-
USB support
Video/Audio/Image
Video/Audio/Image
Video/Audio/Image
- Working Environment
Temperature
5℃~40℃
5℃~40℃
5℃~40℃
-
Humidity
10%~85%
10%~85%
10%~85%
-
Atmospheric Pressure
86KPa~106KPa
86KPa~106KPa
86KPa~106KPa
- Storage Environment
Temperature
-20℃~55℃
-20℃~55℃
-20℃~55℃
-
Humidity
5%~95%
5%~95%
5%~95%
-
Atmospheric Pressure
86kPa~106kPa
86kPa~106kPa
86kPa~106kPa
- Packing list
TV
1
1
1
-
Base
1(optional)
1(optional)
1(optional)
-
Wall bracket
1(optional)
1(optional)
1(optional)
-
Remote control
1
1
1
-
Power cord
1
1
1
-
Instructions
1
1
1
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
